Hot-dip galvanized pole clamps with curved bands and bolted connections for power line hardware. Specify pole diameter and mounting details for a quotation.
WhatsApp：+86 17733036295
E-mail：info@kangnaigu.net
Phone Line：+86 13333199538
Address：Dalian Office, Shahe City, Xingtai City, Hebei Province
Hot-dip galvanized pole clamps with curved bands and bolted connections for power line hardware. Specify pole diameter and mounting details for a quotation.
| Product Name | Hot Dip Galvanized Pole Clamp |
| Standard | Industry standard power pole fitting |
| Material | Q235 Carbon Steel |
| Surface Treatment | Hot dip galvanized; optional: electro zinc plating |
| Structure | Curved steel band with connecting bolts and nuts, split type hoop structure |
| Origin | Hebei · Handan · Yongnian — Integrated Manufacturer & Exporter |
| MOQ | 100 Pcs (negotiable for trial orders) |
| Galvanized Coating Thickness | ≥85μm (Hot-dip galvanized standard) |
| Strength Grade | Q235 |
| Feature | High clamping force, easy installation, good anti-slip performance, suitable for circular pole |
| Working Temperature | -40 ℃ ~ +80 ℃ |
| Service Life | 15–25 years for outdoor exposed environment |
| Hot Dip Galvanized | Main option, excellent corrosion resistance for outdoor overhead power transmission lines |
| Electro Galvanized | Low cost, suitable for indoor or dry environment |
| Model | Inner Diameter(mm) | Band Thickness(mm) | Band Width(mm) | Matched Bolt |
|---|---|---|---|---|
| PC-150 | 150 | 4 | 40 | M12 |
| PC-180 | 180 | 4 | 40 | M12 |
| PC-200 | 200 | 5 | 50 | M16 |
| PC-220 | 220 | 5 | 50 | M16 |
| PC-250 | 250 | 5 | 50 | M16 |
| Applications | Overhead power distribution lines, utility pole fixing, support insulator, crossarm and other power fittings installation on concrete pole or steel pole. |
| Packaging | Woven bag or wooden pallet, waterproof stretch film wrapped |
| Documents | PI, Packing List, Certificate of Origin, Mill Test Certificate |
| Payment Terms | 30% T/T in advance, balance before shipment |
| Lead Time | 3–7 days for regular stock, 7–15 days for customized specifications |
Please tell us the inner diameter you need. We supply hot dip galvanized pole clamps for overhead power distribution projects.
